🆕השקה! VNA חדש: SNA6000A
מנתח הרשתות VNA מסדרת SIGLENT SNA6000A כוללים תחום תדרים של 100 kHz עד 13.5 GHz ו-100 kHz עד 26.5 GHz, ותומכים במדידות פרמטרי פיזור (2/4-port scattering parameters), פרמטרים דיפרנציאליים ופרמטרים במישור הזמן.
בהצלחה למתחרים!
סדרת SNA6000A היא מכשיר אפקטיבי לקביעת מקדם Q, רוחב פס ואובדן הכנסה של מסנן.
היא כוללת המרת אימפדנס, תזוזת מישור המדידה, בדיקת גבולות, בדיקת גלים, סימולציית מתקן והתאמות הסרת/הכנסת מתאמים.
ה-VNA מציעים חמישה סוגי סריקה: Linear-Frequency mode, Log-Frequency mode, Power-Sweep mode, CW-Time mode ו-Segment-Sweep mode.
בנוסף, ה-VNAs מסדרת SNA6000A תומכים בתיקון פרמטרי פיזור של SOLT, SOLR, TRL, Response ו-Enhanced Response, למתן גמישות מוגברת במחקר ופיתוח ויישומים תעשייתיים.
השוואת ה VNA שלנו למתחרים:
| Models | Siglent SNA6000A | Keysight E5071C | Keysight E5080B | R&S ZNB | CM Cobalt C Series | |
| General Information |
Frequency Range | 100 kHz to 13.5/26.5 GHz | 9 kHz to 4.5/6.5/8.5 GHz (without bias tees) 100 kHz to 4.5/6.5/8.5 GHz (with bias tees) 300 kHz to 14/20 GHz (with bias tees) |
9 kHz to 4.5/6.5/9/14/18/20 GHz 100 kHz to 26.5/32/44/53 GHz |
9 kHz to 4.5/8.5 GHz 100 kHz to 20/26.5/43.5 GHz |
100 kHz to 20 GHz |
| Ports | 2 or 4 ports | 2 or 4 ports | 2 or 4 ports | 2 or 4 ports | 2 or 4 ports | |
| VNA Type | Benchtop | Benchtop | Benchtop | Benchtop | Full Rack | |
| Test Set | SNA6034A: 100 kHz to 26.5 GHz, 4 ports, 3.5mm NMD (m) SNA6032A: 100 kHz to 26.5 GHz, 2 ports, 3.5mm NMD (m) SNA6024A: 100 kHz to 13.5 GHz, 4 ports, 3.5mm NMD (m) SNA6022A: 100 kHz to 13.5 GHz, 2 ports, 3.5mm NMD (m) |
Option 240 or 440: 9 kHz to 4.5 GHz, 2 or 4 ports, Type-N (f) Option 245 or 445: 100 kHz to 4.5 GHz, 2 or 4 ports, Type-N (f) Option 260 or 460: 9 kHz to 6.5 GHz, 2 or 4 ports, Type-N (f) Option 265 or 465: 100 kHz to 6.5 GHz, 2 or 4 ports, Type-N (f) Option 280 or 480: 9 kHz to 8.5 GHz, 2 or 4 ports, Type-N (f) Option 285 or 485: 100 kHz to 8.5 GHz, 2 or 4 ports, Type-N (f) Option 2D5 or 4D5: 300 kHz to 14 GHz, 2 or 4 ports, 3.5 mm (m) Option 2K5 or 4K5: 300 kHz to 20 GHz, 2 or 4 ports, 3.5 mm (m) |
Option 240 or 440: 9 kHz to 4.5 GHz, 2 or 4 ports, Type-N (f) Option 260 or 460: 9 kHz to 6.5 GHz, 2 or 4 ports, Type-N (f) Option 290 or 490: 9 kHz to 9 GHz, 2 or 4 ports, Type-N (f) Option 2D0 or 4D0: 9 kHz to 14 GHz, 2 or 4 ports, Type-N (f), 3.5 mm (m) Option 2H0 or 4H0: 9 kHz to 18 GHz, 2 or 4 ports, Type-N (f), 3.5 mm (m) Option 2K0 or 4K0: 9 kHz to 20 GHz, 2 or 4 ports, 3.5 mm (m) Option 2L0 or 4L0: 100 kHz to 26.5 GHz, 2 or 4 ports, 3.5 mm (m) Option 2M0 or 4M0: 100 kHz to 32 GHz, 2 or 4 ports, 2.4 mm (m) Option 2N0 or 4N0: 100 kHz to 44 GHz, 2 or 4 ports, 2.4 mm (m) Option 2P0 or 4P0: 100 kHz to 53 GHz, 2 or 4 ports, 1.85 mm (m) |
ZNB4: 9 kHz to 4.5 GHz, 2 or 4 ports, type N, female ZNB8: 9 kHz to 8.5 GHz, 2 or 4 ports, type N, female ZNB20: 100 kHz to 20 GHz, 2 or 4 ports, 3.5 mm, male ZNB26: 100 kHz to 26.5 GHz, 2 or 4 ports, 2.4 mm, male ZNB43: 100 kHz to 43.5 GHz, 2 or 4 ports, 3.5 mm, male |
C1220: 100 kHz to 20 GHz, 2 ports, 3.5mm NMD (m) C1420: 100 kHz to 20 GHz, 4 ports, 3.5mm NMD (m) |
|
| With Jumper Interface SNA6134A: 100 kHz to 26.5 GHz, 4 ports, 3.5mm NMD (m) SNA6132A: 100 kHz to 26.5 GHz, 2 ports, 3.5mm NMD (m) SNA6124A: 100 kHz to 13.5 GHz, 4 ports, 3.5mm NMD (m) SNA6122A: 100 kHz to 13.5 GHz, 2 ports, 3.5mm NMD (m) |
— | — | — | With Jumper Interface C2220: 100 kHz to 20 GHz, 2 ports, 3.5mm NMD (m) C2420: 100 kHz to 20 GHz, 4 ports, 3.5mm NMD (m) |
||
| Number of Points | 2 to 100,001 | 2 to 20,001 | 1 to 100,003 | 1 to 100,001 | 2 to 500,001 | |
| Jumper Interface / Direct access | יתרון ✅ SNA61xxA only, standard Source, Ref and Meas |
No | No | No | C2x20 only, standard Source, Ref and Meas |
|
| Internal Sources | יתרון ✅ 4-port with internal second source, standard |
1 source | 4-port with internal second source, option | 4-port with internal second source, option | Not mentioned | |
| Bias-Tee | יתרון ✅ Standard |
Standard | Option, Available with 4.5/6.5/9/14/20 GHz options only Cannot be combined with 14 or 18 GHz options with Type-N connectors |
ZNB4/8: Option ZNB20/26/43: Not mentioned |
Not mentioned | |
| GPIB Interface | יתרון ✅ Standard |
Standard | Option | Option | Not mentioned | |
| IFBW | יתרון ✅ 1 Hz to 10 MHz |
10 Hz to 1.5 MHz | 1 Hz to 15 MHz | base unit: 1 Hz to 1 MHz with ZNB-K17 option: 1 Hz to 10 MHz |
2-port: 1 Hz to 1 MHz 4-port: 1 Hz to 2 MHz |
|
| Frequency Resolution | 1 Hz | 1 Hz | 1 Hz | 1 Hz | 1 Hz | |
| Level Resolution | 0.05 dB | 0.05 dB | 0.01 dB | 0.01 dB | 0.05 dB | |
| Dynamic Range (IFBW 10Hz, Spec.) |
120 dB, 100 kHz to 1 MHz 125 dB, 1 MHz to 500 MHz 130 dB, 500 MHz to 1 GHz 135 dB, 1 GHz to 20 GHz 127 dB, 20 GHz to 24 GHz 120 dB, 24 GHz to 26.5 GHz |
4.5/6.5/8.5 GHz models 97 dB, 9 kHz to 300 kHz 107 dB, 300 kHz to 10 MHz 123 dB, 10 MHz to 6 GHz 117 dB, 6 GHz to 8.5 GHz |
4.5/6.5/9/14/18/20 models, with bias tee options 99 dB, 9 kHz to 100 kHz 116 dB, 100 kHz to 300 kHz 124 dB, 300 kHz to 1 MHz 129 dB, 1 MHz to 10 MHz 136 dB, 10 MHz to 50 MHz 138 dB, 50 MHz to 4.5 GHz 136 dB, 4.5 GHz to 6.5 GHz 133 dB, 6.5 GHz to 9 GHz 130 dB, 9 GHz to 14 GHz 126 dB, 14 GHz to 16 GHz 121 dB, 16 GHz to 20 GHz |
4.5/8.5 GHz models ≥ 110 dB, 9 kHz to 100 kHz ≥ 125 dB, 100 kHz to 50 MHz ≥ 130 dB, 50 MHz to 7 GHz ≥ 120 dB, 7 GHz to 8.5 GHz |
C1220/C1420 model 110 dB, 100 kHz to 1 MHz 133 dB, 1 MHz to 20 GHz C2220/C2420 model 110 dB, 100 kHz to 1 MHz 130 dB, 1 MHz to 20 GHz |
|
| — | 14/20 GHz models 95 dB, 300 kHz to 1 MHz 107 dB, 1 MHz to 10 MHz 120 dB, 10 MHz to 100 MHz 123 dB, 100 MHz to 6 GHz 117 dB, 6 GHz to 8.5 GHz 105 dB, 8.5 GHz to 10.5 GHz 100 dB, 10.5 GHz to 15 GHz 96 dB, 15 GHz to 20 GHz |
26.5/32/44/53 GHz models 95 dB, 100 kHz to 300 kHz 104 dB, 300 kHz to 500 kHz 117 dB, 500 kHz to 1 MHz 125 dB, 1 MHz to 10 MHz 137 dB, 10 MHz to 50 MHz 140 dB, 50 MHz to 6.5 GHz 138 dB, 6.5 GHz to 9 GHz 137 dB, 9 GHz to 17 GHz 132 dB, 17 GHz to 20 GHz 130 dB, 20 GHz to 25 GHz 127 dB, 25 GHz to 30 GHz 122 dB, 30 GHz to 45 GHz 99 dB, 45 GHz to 50 GHz 71 dB, 50 GHz to 53 GHz |
20 GHz model ≥ 95 dB, 100 kHz to 300 kHz ≥ 105 dB, 300 kHz to 1 MHz ≥ 115 dB, 1 MHz to 10 MHz ≥ 120 dB, 10 MHz to 100 MHz ≥ 125 dB, 100 MHz to 9 GHz ≥ 120 dB, 9 GHz to 20 GHz 26.5/43.5 GHz models ≥ 120 dB, 100 kHz to 1 MHz ≥ 125 dB, 1 MHz to 10 MHz ≥ 128 dB, 10 MHz to 5 GHz ≥ 125 dB, 5 GHz to 10 GHz ≥ 115 dB, 10 GHz to 30 GHz ≥ 110 dB, 30 GHz to 35 GHz |
|||
| Directivity After Calibration (IFBW 10Hz, Spec.) |
Keysight 85052D (3.5 mm, 50 Ω) 41 dB, 100 kHz to 9 GHz 36 dB, 9 GHz to 20 GHz 35 dB, 20 GHz to 26.5 GHz |
85032F (Type-N, 50 Ω), 4.5/6.5/8.5 GHz models 49 dB, 9 kHz to 10 MHz 46 dB, 10 MHz to 3 GHz 40 dB, 3 GHz to 6 GHz 38 dB, 6 GHz to 20 GHz 85052D (3.5 mm, 50 Ω), 14/20 GHz models 42 dB, 300 kHz to 2 GHz 38 dB, 2 GHz to 6 GHz 36 dB, 6 GHz to 20 GHz |
85052D, 4.5/6.5/9/14/18/20 GHz models 42 dB, 9 kHz to 2 GHz 38 dB, 2 GHz to 8 GHz 36 dB, 8 GHz to 20 GHz N4694D, 26.5/32/44/53 GHz models 41 dB, 100 kHz to 2 GHz 42 dB, 2 GHz to 20 GHz 41 dB, 20 GHz to 30 GHz 40 dB, 30 GHz to 40 GHz |
ZV-Z270, 4.5/8.5 GHz models ≥ 46 dB, 9 kHz to100 kHz ≥ 45 dB, 100 kHz to 4.5 GHz ≥ 40 dB, 4.5 GHz to 8.5 GHz ZN-Z235, 20 GHz model ≥ 46 dB, 100 kHz to 10 GHz ≥ 43 dB, 10 GHz to 20 GHz |
46 dB, 100 kHz to 10 GHz 42 dB, 10 GHz to 20 GHz |
|
| ZN-Z229, 26.5 GHz models ≥ 46 dB, 100 kHz to 10 GHz ≥ 44 dB, 10 GHz to 20 GHz ≥ 42 dB, 20 GHz to 26.5 GHz ZN-Z224, 43.5 GHz models ≥ 46 dB, 100 kHz to 10 GHz ≥ 44 dB, 10 GHz to 20 GHz ≥ 42 dB, 20 GHz to 26.5 GHz |
||||||
| Display | 12.1 inch, touch screen | 10.4 inch, touch screen | 12.1 inch, touch screen | 12.1 inch, touch screen | No | |
| Size (W×H×D) | 426×251×494.5 mm | 426×222×472 mm | 460×266×344 mm | 462.5×239.6×361.5 mm | C1220/C2220 model: 440×140×430 mm C1420/C2420 model: 440×140×600 mm |
|
| Weight | 4 ports: 19 kg | 18.8 kg, Option 230/240/260/280 (2-port) 18.9 kg, Option 235/245/265/285 (2-port) 20.5 kg, Option 430/480/440/460 (4-port) 20.6 kg, Option 435/445/465/485 (4-port) 20.4 kg, Option 2D5/2K5 (2-port) 22.4 kg, Option 4D5/4K5 (4-port) |
2 ports: 14 kg 4 ports: 15 kg |
2 ports: 14 kg 4 ports: 16 kg |
C1220/C2220 model: 14 kg C1420/C2420 model: 22 kg |
|
| Source Frequency Performance |
Source Stability | Standard ± 1.0 ppm (0 to 40 ℃) ± 0.5 ppm/year, ± 3.0 ppm/20 year |
Standard ± 7 ppm (5 to 40 ℃) |
Standard ± 7 ppm (0 to 40 °C) ± 3 ppm/year maximum, typical |
Standard ± 1 ppm (5 to 40 ℃) ± 1 ppm/year |
Not mentioned |
| Option HPR ± 1 ppb (0 to 40 ℃) ± 50 ppb/year |
Option 1E5 ± 0.5 ppm (5 to 40 ℃) ± 0.5 ppm/year |
Option 1E5 ± 0.45 ppm (5 to 40 ℃) ± 0.1 ppm/year maximum, typical |
Option ZNB-B4 ± 0.1 ppm (5 to 40 ℃) ± 0.01 ppm/year |
Not mentioned | ||
| CW Accuracy | Standard: ± 1.0 ppm (23 ± 3℃ ) Option HPR: ± 0.1 ppm (23 ± 3℃ ) |
Standard: ± 7 ppm Option 1E5: ± 0.45 ppm |
Standard: ± 7 ppm Option 1E5: ± 0.45 ppm |
Standard: ± 0.5 ppm Option ZNB-B4: ± 0.05 ppm |
Not mentioned | |
| Source Spectrum Performance | Non-harmonic Spurious | –30 dBc (0 dBm, Spec.) | –30 dBc (5 dBm, Typ.) | -50 dBc, 9/100 kHz to 10 GHz -45 dBc, 10 GHz to 20 GHz -35 dBc, 20 GHz to 53 GHz (0 dBm, Typ.) |
Not mentioned | -30 dBc |
| Harmonics | 2nd or 3rd, 0 dBm, Spec. -20 dBc, 100 kHz to 10 MHz -25 dBc, 10 MHz to 26.5 GHz |
2nd or 3rd, 4.5/6.5/8.5 GHz models, 5 dBm, Typ. –25 dBc, 9 kHz to 2 GHz –20 dBc, 2 GHz to 8.5 GHz 2nd to 5th, 14/20 GHz models, at max. power, Typ. –12 dBc, 300 kHz to 1 GHz –15 dBc, 1 GHz to 20 GHz |
2nd or 3rd, 4.5/6.5/9/14/18/20 GHz models, 0 dBm, Typ. -20 dBc, 30 kHz to 10 MHz -25 dBc, 10 MHz to 20 GHz 2nd or 3rd, 26.5/32/44/53 GHz models, 0 dBm, Typ. -20 dBc, 300 kHz to 1 MHz -25 dBc, 1 MHz to 20 GHz -17 dBc, 20 GHz to 25 GHz -20 dBc, 25 GHz to 40 GHz |
2nd, 26.5 GHz model, 0 dBm, Spec. –15 dBc, 200 kHz to 20 MHz –20 dBc, 20 MHz to 200 MHz –25 dBc, 200 MHz to 20 GHz –18 dBc, 20 GHz to 26.5 GHz 3rd, 26.5 GHz model, 0 dBm, Spec. –15 dBc, 300 kHz to 30 MHz –20 dBc, 30 MHz to 300 MHz –25 dBc, 300 MHz to 26.5 GHz |
-25 dBc | |
| Source Power Performance |
Output Power (Spec.) |
יתרון ✅ -55 to 10 dBm, 100 kHz to 20 GHz -55 to 7 dBm, 20 GHz to 24 GHz -55 to 5 dBm, 24 GHz to 26.5 GHz |
4.5/6.5/8.5 GHz models –55 to 10 dBm, 9 kHz to 5 GHz –55 to 9 dBm, 5 GHz to 6 GHz –55 to 8 dBm, 6 GHz to 7 GHz –55 to 7 dBm, 7 GHz to 8.5 GHz |
4.5/6.5/9/14/18/20 GHz models, with bias tee options extend power range option -60 to -1 dBm, 9 kHz to 100 kHz -60 to 4.5 dBm, 100 kHz to 10 MHz -60 to 9.5 dBm, 10 MHz to 50 MHz -60 to 9 dBm, 50 MHz to 4.5 GHz -60 to 8 dBm, 4.5 GHz to 6.5 GHz -60 to 7.5 dBm, 6.5 GHz to 9 GHz -60 to 5.5 dBm, 9 GHz to 14 GHz -60 to 5 dBm, 14 GHz to 16 GHz -60 to 1.5 dBm, 16 GHz to 20 GHz |
4.5/8.5 GHz models –55 to +10 dBm, 9 kHz to 100 MHz –55 to +13 dBm, 100 MHz to 2.5 GHz –55 to +10 dBm, 2.5 GHz to 7.5 GHz –55 to +8 dBm, 7.5 GHz to 8.5 GHz 20 GHz model –30 to +12 dBm, 100 kHz to 10 GHz –30 to +10 dBm, 10 GHz to 20 GHz |
-60 dBm to +10 dBm |
| 14/20 GHz models –55 to 8 dBm, 300 kHz to 1 MHz –55 to 10 dBm, 1 MHz to 6 GHz –55 to 9 dBm, 6 GHz to 8 GHz –55 to 7 dBm, 8 GHz to 10.5 GHz –55 to 3 dBm, 10.5 GHz to 15 GHz –55 to 0 dBm, 15 GHz to 20 GHz |
26.5/32/44/53 GHz models -60 to -2 dBm, 100 kHz to 300 kHz -60 to 7 dBm, 300 kHz to 1 MHz -60 to 10 dBm, 1 MHz to 17 GHz -60 to 7 dBm, 17 GHz to 20 GHz -60 to 5 dBm, 20 GHz to 30 GHz -60 to 2 dBm, 30 GHz to 45 GHz -60 to -6 dBm, 45 GHz to 50 GHz -60 to -24 dBm, 50 GHz to 53 GHz |
26.5/43.5 GHz models –30 to +7 dBm, 100 kHz to 300 kHz –30 to +10 dBm, 300 kHz to 1 GHz –30 to +8 dBm, 1 GHz to 10 GHz –30 to +6 dBm, 10 GHz to 15 GHz –30 to +5 dBm, 15 GHz to 20 GHz –30 to +0 dBm, 20 GHz to 30 GHz |
||||
| Receiver Performance |
Noise Floor (Spec.) |
יתרון ✅ -115 dBm/Hz, 100 kHz to 500 MHz -125 dBm/Hz, 500 MHz to 1 GHz -130 dBm/Hz, 1 GHz to 8 GHz -135 dBm/Hz, 8 GHz to 20 GHz -130 dBm/Hz, 20 GHz to 26.5 GHz |
4.5/6.5/8.5 GHz models –97 dBm/Hz, 9 kHz to 300 kHz –107 dBm/Hz, 300 kHz to 10 MHz –123 dBm/Hz, 10 MHz to 5 GHz –124 dBm/Hz, 5 GHz to 6 GHz –119 dBm/Hz, 6 GHz to 7 GHz –120 dBm/Hz, 7 GHz to 8.5 GHz |
4.5/6.5/9/14/18/20 GHz models, with bias tee options -100 dBm/Hz, 9 kHz to 100 kHz -112 dBm/Hz, 100 kHz to 300 kHz -120 dBm/Hz, 300 kHz to 1 MHz -125 dBm/Hz, 1 MHz to 10 MHz -127 dBm/Hz, 10 MHz to 50 MHz -129 dBm/Hz, 50 MHz to 4.5 GHz -127 dBm/Hz, 4.5 GHz to 6.5 GHz -126 dBm/Hz, 6.5 GHz to 9 GHz -125 dBm/Hz, 9 GHz to 14 GHz -121 dBm/Hz, 14 GHz to 16 GHz -120 dBm/Hz, 16 GHz to 20 GHz |
4.5/8.5 GHz models –120 dBm, 9 kHz to 100 kHz –130 dBm, 100 kHz to 4 GHz –125 dBm, 4 GHz to 6.5 GHz –120 dBm, 6.5 GHz to 8.5 GHz 20 GHz model –105 dBm, 100 kHz to 1 MHz –115 dBm, 1 MHz to 10 MHz –120 dBm, 10 MHz to 15 GHz –118 dBm, 15 GHz to 20 GHz |
C1220/C1420 model -110 dBm/Hz, 100 kHz to 1 MHz -133 dBm/Hz, 1 MHz to 20 GHz C2220/C2420 model -110 dBm/Hz, 100 kHz to 1 MHz -130 dBm/Hz, 1 MHz to 20 GHz |
| 14/20 GHz models –97 dBm/Hz, 300 kHz to 1 MHz –107 dBm/Hz, 1 MHz to 10 MHz –120 dBm/Hz, 10 MHz to 100 MHz –123 dBm/Hz, 100 MHz to 6 GHz –118 dBm/Hz, 6 GHz to 8 GHz –120 dBm/Hz, 8 GHz to 8.5 GHz –108 dBm/Hz, 8.5 GHz to 10.5 GHz –107 dBm/Hz, 10.5 GHz to 15 GHz –106 dBm/Hz, 15 GHz to 20 GHz |
26.5/32/44/53 GHz models -97 dBm/Hz, 100 kHz to 500 kHz -110 dBm/Hz, 500 kHz to 1 MHz -115 dBm/Hz, 1 MHz to 10 MHz -127 dBm/Hz, 10 MHz to 50 MHz -130 dBm/Hz, 50 MHz to 6.5 GHz -128 dBm/Hz, 6.5 GHz to 9 GHz -127 dBm/Hz, 9 GHz to 17 GHz -125 dBm/Hz, 17 GHz to 25 GHz -122 dBm/Hz, 25 GHz to 30 GHz |
26.5/43.5 GHz models –110 dBm, 100 kHz to 300 kHz –115 dBm, 300 kHz to 1 MHz –120 dBm, 1 MHz to 5 GHz –118 dBm, 5 GHz to 20 GHz –115 dBm, 20 GHz to 30 GHz |
||||
| Receiver Compression | Magnitude, 10 dBm, Spec. 0.5 dB, 100 kHz to 13.5 GHz 1.0 dB, 13.5 GHz to 26.5 GHz |
Magnitude, 10 dBm, SPD, 4.5/6.5/8.5 GHz models 0.08 dB, 9 kHz to 5 GHz 0.1 dB, 5 GHz to 8.5 GHz |
Magnitude, 4.5/6.5/9/14/18/20 GHz models, with bias tee options, Spec. 0.5 dB, 9 kHz to 100 kHz, -1 dBm 0.2 dB, 100 kHz to 10 MHz, -4.5 dBm 0.2 dB, 10 MHz to 50 MHz, -9.5 dBm 0.2 dB, 50 MHz to 4.5 GHz, -9 dBm 0.2 dB, 4.5 GHz to 6.5 GHz, -8 dBm 0.2 dB, 6.5 GHz to 9 GHz, -7.5 dBm 0.2 dB, 9 GHz to 14 GHz, -5.5 dBm 0.2 dB, 14 GHz to 16 GHz, -5 dBm 0.2 dB, 16 GHz to 20 GHz, -1.5 dBm |
4.5/8.5 GHz models 0.2 dB, 9 kHz to 8.5 GHz, 0 dBm to +8 dBm 0.2 dB, 9 kHz to 7.5 GHz, +8 dBm to +10 dBm 20 GHz model 0.3 dB, 100 kHz to 15 GHz, 0 dBm to +10 dBm 0.3 dB, 15 GHz to 20 GHz, 0 dBm to +8 dBm 26.5/43.5 GHz models 0.2 dB, 100 kHz to 20 GHz, 0 dBm to +5 dBm |
Not mentioned | |
| Magnitude, 10 dBm, SPD, 14/20 GHz models 0.3 dB, 300 kHz to 10 MHz 0.182 dB, 10 MHz to 10 GHz 0.712 dB, 10 GHz to 15 GHz 1.87 dB, 15 GHz to 20 GHz |
Magnitude, 26.5/32/44/53 GHz models, Spec. 0.2 dB, 100 kHz to 300 kHz, -2 dBm 0.2 dB, 300 kHz to 1 MHz, +7 dBm 0.2 dB, 1 MHz to 17 GHz, +10 dBm 0.2 dB, 17 GHz to 20 GHz, +7 dBm 0.2 dB, 20 GHz to 30 GHz, +5 dBm 0.2 dB, 30 GHz to 45 GHz , +2 dBm 0.2 dB, 45 GHz to 50 GHz , -6 dBm 0.2 dB, 50 GHz to 53 GHz, -24 dBm |
|||||
| Option | Time Domain Analysis | SNA6000-TDA | S96010B | S96010B | ZNB-K2 | Standard |
| Extended Time Domain | SNA6000-TDR | S96011B | S96011B | ZNB-K20 | No | |
| Scalar Mixer Measurement | SNA6000-SMM | No | S96082B | ZNB-K4 | No | |
| Spectrum Analysis | יתרון ✅ SNA6000-SA |
No | with Option 09x (HW) and S96090B (SW) | No | No | |
| Pulsed-RF Measurement | יתרון ✅ SNA6000-PM |
No | with Option 021/022 (HW) and S96025B (SW) | No | No | |
| Material Measurement | SNA6000-MT | No | N1500A-001 | No | No | |
| Overall: | יתרון ✅ |
